Application:
This Fixed Hydraulic Crusher is mainly applicable to:
1、 Mine (mountain cutting, mining, grilling crush, secondary crush etc.);
2、 Thermal power station (frozen coal or coarse coal);
3、 Metallurgy (slag clearing, equipment basically dismantling etc.);
4、 Other industries (ice breaking, frozen earth breaking, sand vibrating etc.).
Characteristic:
This crusher is developed by our company on the real condition of the crushing site. Adopting international advanced technique, the crusher selects oversea hydraulic hammer and effectively enhances the impact force through the principle of hydraulic and pneumatic energy used together.
It has reliable performance, convenient operation, and it reduces the labor intensity of workers, improves construction condition in special environment, and increases working efficiency; thus, it is the ideal equipment for secondary crushing mechanization.
|
|
Main Techincal Parameter
|
Type |
SKB-200 |
SKB-400 |
SKB-500 |
SKB-600 |
SKB-1000 |
SKB-1300 |
|||
|
Crushing Capacity（m3/8h） |
80-200 |
200-400 |
300-500 |
350-600 |
700-1000 |
700-1000 |
|||
|
Operating Distance （m） |
2-6 |
2-6 |
2-6 |
2-8 |
2-9 |
2-9 |
|||
|
Turning Angle （α） |
±60° |
||||||||
|
Main Parameter of Hydraulic Station |
Working Pressure |
（Mpa） |
9.1-12.2 |
12.2-16.3 |
12.2-16.3 |
13.2-17.3 |
15.3-17.3 |
16.3-18.3 |
|
|
（kgf/cm3） |
90-120 |
120-160 |
120-160 |
130-170 |
150-170 |
160-180 |
|||
|
Oil Flow（L/min） |
20-40 |
30-60 |
35-70 |
40-85 |
80-110 |
120-150 |
|||
|
Power（kW） |
22 |
30 |
30 |
30 |
37 |
55 |
|||
|
Poke Bar Diameter（mm） |
56 |
65 |
70 |
85 |
100 |
138 |
|||
|
Impact Rate（b.p.m.） |
500-1200 |
500-1000 |
450-800 |
450-750 |
450-700 |
325-500 |
|||
|
Weight （t） |
9.0 |
9.4 |
9.6 |
11.0 |
12.4 |
13.0 |
|||
|
Notice:1. Operating distance can be lengthened according to actual requirements; 2. Turning angle can be enlarged according to actual requirements |
|||||||||
